FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring

Name: FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring
Brand: HILINK
Price: 1 USD

Wholesale FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring from china suppliers

Brand Name : HILINK

Model Number : HL-SW1X2

Certification : CE FCC Rohs

Place of Origin : China

MOQ : 1pcs

Payment Terms : Western Union, L/C, T/T

Supply Ability : 5000pcs/week

Delivery Time : 1-4 working days

Packaging Details : Static bag, Plastic PVC Pack, Retail box

Price : Negotiable

Operating wavelength : 1260-1620nm

Wavelength : 1310nm&1550nm

Connector : LC/SC FC

Operating temperature : -20~70℃

Warranty : 3 Years

Midea type : Single mode

Insertion Loss : 0.8db

Contact Now

FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring

General

The 1x2 Micro Mechanical Bi-directional Fiber Optic Switch connects optical channels by redirecting 1 incoming optical signals into 2 output fibers. The switch has integrated electrical position sensors.Based on thin film filter technology that provides a robust method of altering the light patch, this series of products has a drastically simplified platform configuration offering high reliability and low production cost.

This novel design significantly reduces moving part position sensitivity, offering unprecedented high stability as well as an unmatched low cost.

Features

♦ Low Insertion loss

♦ Wide Wavelength Range

♦ Low Crosstalk

♦ High Stability, High Reliability

♦ Epoxy-free on Optical Path

♦ Latching and Non-latching

♦ Channel Blocking

♦ Configurable Add/Drop

♦ System Monitoring

♦ Single mode or Multimode optional

1X2 Applications
Optical Network
Protection/Restoration
Optical Singnal Routing
Configurable Optical Add/Drop
Transmitter and receiver protection

Instrumentation, testing, and measurement

FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring

Parameters		FSW-1×2-SM
Wavelength Range	nm	850±40 / 1300±40	1260~1650
Operating Wavelength	nm	850/1300	1310/1490/1550/1625/1650
Insertion Loss	dB	Typ:0.8 Max:1.2	Typ:0.5 Max:1.0
Return Loss	dB	MM≥30 SM≥50
Crosstalk	dB	MM≥35 SM≥55
PDL	dB	≤0.05
WDL	dB	≤0.25
TDL	dB	≤0.25
Repeatability	dB	≤±0.02
Power Supply	V	3.0 or 5.0
Lifetime	Time	≥107
Switch Time	ms	≤8
Transmission Power	mW	≤500
Operating Temperature	℃	-20~+80
Storage Temperature	℃	-40~+85
Weight	g	16
Dimension	mm	(L)27×(W)12.0×(H)8.2

Optical Route

FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring

PIN Define

Control Model	Optical Path	Electric Drive				Status Sensor
1×2		1	5	6	10	2-3	3-4	7-8	8-9
Latching	P1-P2	--	--	GND	V+	Close	Open	Open	Close
Latching	P1-P3	V+	GND	--	--	Open	Close	Close	Open
Non-latching	P1-P2	--	--	--	--	Close	Open	Open	Close
Non-latching	P1-P3	V+	--	--	GND	Open	Close	Close	Open

Order Information

Mode	Wavelength	Voltage Type	Control Type	Fiber Type	Fiber Diameter	Fiber Length	Connector
S=SM M=MM	85=850nm 13=1310nm 15=1550nm 13/15=1310/1550nm X=Others	3=3V 5=5V	L=Latching N=Non- Latching	5=50/125 6=62.5/125 9=9/125 X=Others	25=250um 90=900um 20=2.0mm 30=3.0mm X=Others	1=1m 2=2m X=Others	0=None 1=FC/PC 2=FC/APC 3=SC/PC 4=SC/APC 5=ST/PC 6=ST/APC 7=LC/PC 8=LC/APC

FC Connectors Micro Fiber 1x2 Mechanical Optical Switch SMF For System Monitoring
