10 GBASE-BX WDM Single Mode Fiber Module 10G 1270/1330nm 60km DOM BiDi SFP+ LC Single Core

Name: 10 GBASEBX WDM Single Mode Fiber Module 10G 12701330nm 60km DOM BiDi SFP LC Single Core
Brand: HILINK
Price: 1 USD

Wholesale 10 GBASE-BX WDM Single Mode Fiber Module 10G 1270/1330nm 60km DOM BiDi SFP+ LC Single Core from china suppliers

Brand Name : HILINK

Model Number : HL-10BS-60

Certification : CE/FCC/RoHS

Place of Origin : Guangdong, China

MOQ : 1pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 3000 pairs per Week

Delivery Time : 1-4 days

Packaging Details : Carton box, Retail box, Or by required

Data transfer rate : 10Gbps

Max Distance : 60km

Wavelength : 1270nm/1330nm

Interface : LC

Warranty : 3 Years

Contact Now

10Gbps BiDi SFP+ Optical Transceiver, 10G WDM SFP+ 60km for Wired Single Fiber

10G BiDi SFP+ transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by using 1330nm (1270nm) transmitter and 1270nm (1330nm) receiver. It uses a single fiber to transmitter and receive the data rate, which is very cost-effective in optic equipment.

Features:

1. 10Gbps Data transfer rate
2. Tx1270nm/Rx1330nm and Tx1330nm/Rx1270nm BiDi SFP
3. Distance up to 60km
4. Single 3.3V Power Supply and TTL Logic Interface
5. Hot-Pluggable SFP
6. Simplex LC Connector
7. Compliant with SFP MSA
8. Digital Diagnostic Monitoring
9. Operating Temperature Standard: 0~70℃

Date Rate	10G	Fiber Type	SMF
Max Distance	60km	Wavelength	1270nm/1330nm
Transmmit	DFB Laser	Receiver	APD Receiver
Form Type	SFP+	DOM	Support
Commercial Temperature	0-70	Interface	LC

Applications:
1. Fiber Channel Links
2. Gigabit Ethernet
3. Other Optical Links

10 GBASE-BX WDM Single Mode Fiber Module 10G 1270/1330nm 60km DOM BiDi SFP+ LC Single Core

10G SFP+ BiDi	SFP+ BiDi 10km	SFP+ BiDi 10km 1270nm/1330nm LC
	SFP+ BiDi 20km	SFP+ BiDi 20km 1270nm/1330nm LC
	SFP+ BiDi 40km	SFP+ BiDi 20km 1270nm/1330nm LC
	SFP+ BiDi 60km	SFP+ BiDi 60km 1270nm/1330nm LC
	SFP+ BiDi 80km	SFP+ BiDi 80km 1490nm/1550nm LC

Optical Transceiver good compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
