C-band Tunable 10GBASE-ZR 10G DWDM Multi-rate 80KM SMF Optical Modules for OTN
Hilink C-band Tunable SFP+ transceivers are designed for use in 1Gbps to 11.3Gbps multi-rate 50GHz/100GHz DWDM links up to 80km of G.652 single mode fiber.
Compatible with multiple network applications and transmission formats: CPRI, OTN, Fibre Channel, etc. Hot pluggable, and with narrow band tunability, it significantly reduces sparing and configuring costs in optical networks.
The module is optimised for Local Area Networks (LAN), Mobile Fronthaul and 10G Ethernet (10GbE), over single-mode fibre (SMF) optical links, P2P and passive networks. Optional G.Metro feature enables wavelength auto-tuning over Fibre. Digital Optical Monitoring interfaces are provided via the SFP+ standards compliant I2C interface.
Features
- Hot-pluggable SFP+ form factor
- Supports 1.0 - 11.3Gbps data rate (9.8 - 11.3 for CDR enabled models)
- 50GHz/100GHz ITU channel spacing (C-Band)
- Duplex LC connector
- Maximum link length of 80km
- C-band-tunable laser and high-performance APD photo-detector
- Single 3.3V power supply
- Power dissipation < 2.3W with CDR for Industrial temperature
- Built-in digital diagnostic functions
- RoHS 2.0 compliant (2011/65/EU, lead free)
- Case temperature range: Commercial 0~70℃ / Industrial -40~85℃ optional
Specifications & Parameters
| Item No.d | DW-SFP10GX-80-T | Vendor Name | Hilink |
| Form Type | SFP+ | Max Data Rate | 10Gbps |
| Wavelength | DWDM CH17-CH61 | Max Cable Distance | 80KM |
| Interface | LC duplex | Optical Components | EML DWDM |
| Cable Type | SMF | DOM Support | Yes |
| TX Power | -2~4dBm | Receiver Sensitivity | <-21dBm |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) | HTS-Harmonized Code | 8517706000 |
Transmit Characteristics
| Parameter | Min | Max | Unit |
| Data rate | 1.0 | 11.3 | Gbps |
| Optical output power | -2 | +4 | dBm |
| Side-Mode Suppression Ratio | 35 | | dB |
| Extinction ratio (NRZ, filtered) | 8.2 | | dB |
| Spectral excursion | -11 | +11 | GHz |
| Optical Frequency Tuning Range (4 bands) | 196.05 (1529.16) | 191.30 (1567.14) | THz(nm) |
Receive Characteristics
| Parameter | Min | Max | Unit |
| Data rate | 1.0 | 11.3 | Gbps |
| Maximum bit error ratio(10Gbps) | | 1e-12 | - |
| Receiver wavelength range | 1260 | 1600 | THz(nm) |
| Receive Sensitivity | | -21 | dBm |
| Receiver optical reflectance | | -27 | dB |
| LOS assert | -34 | | dBm |
| LOS de-assert | | -25 | dBm |
| LOS Hysteresis | 0.5 | | dB |
Hilink optical Transceiver 100% compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Mikrotik, Finisar, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
Applications
-
10G Fiber Channel
-
Other optical links
-
SONET/SDH
-
DWDM Systems
DWDM Solution Example
