100M CXP full duplex Optical Transceiver Module 100GBASE - SR10 12 channel

Brand Name : Hilink
Model Number : HCX-MPO121-SR10C
Certification : CE, ROHS, FCC
Place of Origin : China
MOQ : 1 PCS
Payment Terms : T/T, Western Union, Paypal
Delivery Time : 3-6 days
Packaging Details : Poly bag
Data Rate : 120G
Channel : 12 ch
Length : 300M
Fiber : MMF
Cable : OM3 OM4
Certificates : CE, ROHS, FCC
Contact Now

100M CXP full duplex Optical Transceiver Module 100GBASE - SR10 12 channel


Features


12-channel full-duplex transceiver module

Hot Pluggable CXP footprint

Maximum link length of 300m on OM3 or 400m on OM4 Multimode Fiber (MMF)

Multirate capability: 1.06Gb/s to 10.5Gb/s per channel

Unretimed CPPI electrical interface

Requires 3.3V power supply only

Low power dissipation: <3.5W

Reliable VCSEL array technology

Built-in digital diagnostic functions

Commercial operating case temperature range: 0°C to 70°C

Single MPO connector receptacle

RoHS-6 Compliant (lead-free)


Applications


100GBASE-SR10 100G Ethernet

Multiple 1G/2G/4G/8G/10G Fibre Channel

Infiniband transmission at 12ch SDR, DDR and QDR

Switches, Routers

Data Centers

Other 120G Interconnect Requirement


Description


Hilink’s HCX-MPO121-SR10C CXP transceiver modules is a high performance, low power consumption, long reach interconnect solution supporting 100G Ethernet, Infiniband QDR,DDR,SDR,1G/2G/4G/8G/10G fiber channel and PCIe. It is compliant with the 120Gbits Small Form factor Hot-Pluggable CXP-interface. Hilink’s CXP transceiver modulesis an assembly of 12 full-duplexlanes, where each lane is capable of transmitting data at rates up to 10.5Gb/s, providing an aggregated rate of 120Gb/s.
